PS 500-36

PS 500-36

Standard Power Supply Series PS for Bion Technologies fixtures

The power supply units PS 500 are universal power components for all BION TECHNOLOGIES lighting fixtures with external power supply. All PS-series power supply units have been developed as no-noise applications. In these units there are no built-in components, like cooling fans, which could lead to noise generation. Ideal for acoustically sensitive areas such as sales environments, churches and concert halls!

Quicklinks

Dimensions

350 mm x 320 mm x 90 mm [L x D x H]
13.78 in x 12.60 in x 3.55 in [L x D x H]
ControlDMX

2 x DMX in (RJ45 internal)
2 x DMX out (RJ45 internal)
Input Voltage
Power Supply: Internal | 100 - 240, 277 VAC (50 - 60 Hz) | 127 - 431 VDC
Power ConsumptionMax. 500 W
Power Factor Correction> 0,9 @ max. Load
Protection ClassI
Output Voltage

36 V
12 x Terminalblock (6 lines, max 180 W each line, max. 480 W total)
InrushMax. 150 A
Operating Temperature-20 °C / +40 °C | -4 °F / +104 °F
HousingSteel-sheet, powdercoated
Housing Color(s)White (RAL 9010)
Weight
7,5 kg(16.53 lbs)
Ingress ProtectionIP20
Environment
Certification
