tantulus eco indoor
pureWhite | pureColor

Economic cove lighting solution providing the highest light quality

The tantulus 3 eco was developed for the specific needs of indirect lighting of coves and niches. Not only does the updated version offer more efficiency and light quality, it also comes with significantly extended fixture chain length options. Thanks to its Single-BIN LED selection, the tantulus fixture family guarantees excellent homogeneity plus color location stability.

Dimensions

23 mm x 19 mm [W x H]
0.91 in x 0.75 in [W x H]

Standard Unit Lengths210 mm, 310 mm, 415 mm, 515 mm, 615 mm, 720 mm, 820 mm, 920 mm, 1025 mm, 1125 mm, 1225 mm, 1330 mm, 1430 mm, 1530 mm, 1635 mm, 1735 mm, 1835 mm
8.27 in, 12.21 in, 16.34 in, 20.28 in, 24.22 in, 28.35 in, 32.29 in, 36.23 in, 40.36 in, 44.30 in, 48.23 in, 52.37 in, 56.30 in, 60.24 in, 64.37 in, 68.31 in, 72.25 in
Luminaire Type
  pureWhite
  pureColor
pureWhite Color Temperatures2000 K, 2200 K, 2500 K, 2700 K, 3000 K, 3500 K, 4000 K, 4500 K, 6500 K
* Project-specific color temperatures for pureWhite available.
pureColor LED-ColorsRed, Green, Blue
Beam Angles
Lumen Output
210 mm (8,27 in):218 lm
310 mm (12,21 in):330 lm
415 mm (16,34 in):439 lm
515 mm (20,28 in):548 lm
615 mm (24,22 in):660 lm
720 mm (28,35 in):769 lm
820 mm (32,29 in):878 lm
920 mm (36,23 in):990 lm
1025 mm (40,36 in):1099 lm
1125 mm (44,30 in):1208 lm
1225 mm (48,23 in):1320 lm
1330 mm (52,37 in):1429 lm
1430 mm (56,30 in):1538 lm
1530 mm (60,24 in):1650 lm
1635 mm (64,37 in):1759 lm
1735 mm (68,31 in):1868 lm
1835 mm (72,25 in):1980 lm
Light Source
210 mm (8,27 in):7
310 mm (12,21 in):10
415 mm (16,34 in):13
515 mm (20,28 in):17
615 mm (24,22 in):20
720 mm (28,35 in):23
820 mm (32,29 in):27
920 mm (36,23 in):30
1025 mm (40,36 in):33
1125 mm (44,30 in):37
1225 mm (48,23 in):40
1330 mm (52,37 in):43
1430 mm (56,30 in):47
1530 mm (60,24 in):50
1635 mm (64,37 in):53
1735 mm (68,31 in):57
1835 mm (72,25 in):60
Color Rendering Index Ra >= 80
R920
LED-Binning
MacAdam Ellipses Binning2
DimmingExternal
Input Voltage
Power Supply: External | 36 VDC
Power Consumption
210 mm(8,27 in):  Max. 3 W
310 mm(12,21 in):  Max. 3 W
415 mm(16,34 in):  Max. 6 W
515 mm(20,28 in):  Max. 6 W
615 mm(24,22 in):  Max. 6 W
720 mm(28,35 in):  Max. 9 W
820 mm(32,29 in):  Max. 9 W
920 mm(36,23 in):  Max. 9 W
1025 mm(40,36 in):  Max. 12 W
1125 mm(44,30 in):  Max. 12 W
1225 mm(48,23 in):  Max. 12 W
1330 mm(52,37 in):  Max. 15 W
1430 mm(56,30 in):  Max. 15 W
1530 mm(60,24 in):  Max. 15 W
1635 mm(64,37 in):  Max. 18 W
1735 mm(68,31 in):  Max. 18 W
1835 mm(72,25 in):  Max. 18 W
Protection ClassII
Storage Temperature-20 °C / +40 °C | -4 °F / +104 °F
Operating Temperature-20 °C / +40 °C | -4 °F / +104 °F
Start-up Temperature-20 °C / +40 °C | -4 °F / +104 °F
Lumen Maintenance [L70]65’000 h @ 25 °C (77 °F) | 40‘000 h @ 50 °C (122 °F)
LED-ClassClass 2 LED Product
HousingAluminium
Housing Color(s)
Aluminium
Aluminium anodized (Standard)
Lens

Material: PMMA
Translucency

clear 90%
frost  87%
white 70%
Ingress ProtectionIP20
Environment
Certification

Accessories

VS 300-36
VS 300-36
VS 600-36
VS 600-36
Power Supply ND Series
Power Supply ND Series
Power Supply ED Series
Power Supply ED Series
tantulus leader cable
tantulus leader cable
tantulus connection cable
tantulus connection cable
tantulus 3 Bracket 0°
tantulus 3 Bracket 0°
tantulus 3 Bracket 15°
tantulus 3 Bracket 15°
tantulus 3 Bracket 30°
tantulus 3 Bracket 30°
tantulus 3 Bracket 45°
tantulus 3 Bracket 45°
tantulus 3 Bracket 60°
tantulus 3 Bracket 60°
tantulus 3 Positioning Hinge
tantulus 3 Positioning Hinge

Your order code:

  Send request When the background gets green, your selection is complete!

Please choose from the options below.

* mandatory fields

TYP - LUMINOUS COLOR
  1. pureWhite - 2000 K
  2. pureWhite - 2200 K
  3. pureWhite - 2500 K
  4. pureWhite - 2700 K
  5. pureWhite - 3000 K
  6. pureWhite - 3500 K
  7. pureWhite - 4000 K
  8. pureWhite - 4500 K
  9. pureWhite - 6500 K
  10. pureColor - Red
  11. pureColor - Green
  12. pureColor - Blue
FIXTURE LENGTH
  1. 210 mm / 8.27 in
  2. 310 mm / 12.21 in
  3. 415 mm / 16.34 in
  4. 515 mm / 20.28 in
  5. 615 mm / 24.22 in
  6. 720 mm / 28.35 in
  7. 820 mm / 32.29 in
  8. 920 mm / 36.23 in
  9. 1025 mm / 40.36 in
  10. 1125 mm / 44.30 in
  11. 1225 mm / 48.23 in
  12. 1330 mm / 52.37 in
  13. 1430 mm / 56.30 in
  14. 1530 mm / 60.24 in
  15. 1635 mm / 64.37 in
  16. 1735 mm / 68.31 in
  17. 1835 mm / 72.25 in
BEAM ANGLE
  1. 30° x 120° frost
  2. 60° x 120° frost
  3. 90° x 120° frost
  4. 120° x 120° clear
  5. 120° x 120° frost
  6. 120° x 120° white
  7. 186° x 110° white
MOUNTING OPTION
  1. K0 - Bracket Set 0°
  2. K15 - Bracket Set 15°
  3. K30 - Bracket Set 30°
  4. K45 - Bracket Set 45°
  5. K60 - Bracket Set 60°
  6. KADJ - Positioning Hinge
Max. Fixtures per Feed

CE max. 12,28 m (40 ft)
cETLus Class 2 max. 10,34 m (33 ft)

Max. Total Run Length

CE max. 27,28 m (89.5 ft)
cETLus Class 2 max.  25,34 m (83.2 ft)
including 15 m (49.2 ft) leader cable
